Water Still Apparatus

Product Description

Application of this stainless steel made Water Still Apparatus can be noticed in research laboratory. It requires 220Watt voltage and it is offered with 12 months of warranty period. It is used for producing distilled water. This lab apparatus uses heated quartz tube for distillation purpose. Temperature of this Water Still Apparatus is controlled by relay for reliable operation. Simple operating system, high strength, precise dimension, long lasting quality and rust proof design are the key characteristics of this system. Stainless steel made heating electrode of this lab apparatus ensures about its reliable functioning. Water level of its evaporation chamber is controlled automatically.

Water Still

Table Pattern-Barn-stead

Specification

Double walled construction with inner and outer chamber made of S.S. The condenser and top are also made of S.S. The raw water is first made of pass around the tubes in the condenser where it gets heated nearly to the boiling point thus economizing the heating energy. The heated water pass to the evaporator through a water level maintaining pipe. Excess water is let out through the drain. To work on 220/230 volts A.C. supply.

Capacity Load

2 ltrs/hr. 2.0 KW

4 ltrs/hr. 3.0 KW

6 ltrs/hr. 4.0KW

8 ltrs/hr. 5.0 KW

20 ltrs/hr. 8.0 KW
