Projection Microscope

Get a Price/Quote

MOQ : 1 , , Piece

Projection Microscope Specification

View Head
Monocular, vertical projection head

Focus System
Coarse & fine adjustment knob

Features
Live image projection, high-resolution imaging, ideal for teaching and demonstration

Spare Parts
Lamp, fuse, eyepiece, cover, objective

Theory
Video Microscope

Drawtube
Monocular projection tube

Sensor
High sensitivity image sensor

Resolution
1280 x 1024 pixels

Interface
USB 2.0 or VGA output

Frame Rate
Up to 30 fps

Focal Distance
Adjustable, typically 7-15 mm

Magnification
40x

Dimensions
Approx. 220 x 310 x 450 mm

Focus Range
0-20 mm

Eyepieces
Wide field, 10x standard

Eyepiece Tube
Inclined 45, rotatable 360

Illumination
Built-in halogen/LED lamp

Coarse Adjustment Range
Approx. 20 mm

Fine Adjustment Range
2 mm precision

Working Stage
Mechanical, double layer, 120 x 120 mm

Still Image Capture Resolution
1280 x 1024 pixels

Video Capture Resolution
1280 x 720 pixels

Image Format
jpge

Interpupillary Distance
55-75 mm adjustment

Objective Achromatic
4x, 10x, 40x standard

Light Source
6V/20W halogen or LED

Projection Microscope Trade Information

Minimum Order Quantity
1 , , Piece

FOB Port
EXW

Supply Ability
1 , , Piece Per Day

Delivery Time
15 Days

Sample Available
Yes

Sample Policy
Sample costs shipping and taxes has to be paid by the buyer

Packaging Details
standard packing

Main Domestic Market
All India

Certifications
iso ce

About Projection Microscope

Projection Microscope

Specification

We are a well established organization engaged in manufacturing, supplying and exporting Projection Microscope. Offered microscope is made using modern methods and latest technology under the supervision of our expertise team. These microscopes are widely used in research centers, schools, colleges and various laboratories for testing and experimenting purpose. Offered microscope is appreciated for its compact design, easy usage, tough construction and seamless finish. Owing to these features, Projection Microscope is widely demanded around the globe. Customers can avail the best microscope from us.

Other Information:

Microscope Body is heavy duty, inclined monocular type with sturdy base.
Equipped with Coarse & Fine Focusing systems with Quadruple revolving Nose Piece.
Plain stage (120x120mm) with graduated Mechanical Stage for X-Y movements of specimen slide.
Built in light by 6V-20W halogen lamp with continuously variable light intensity control.
The whole system of condenser & light arrangement is moveable up & down by rack & pinion to get the optimum results.
Projection Doom of screen size 150 mm is rotatable through 360°.
Objectives : Achromatic 10x & 20x/40x (SL)
Projection Eye Piece : 10x (Huy)

Packed in a thick and plywood box.

Clear Group Viewing Experience

Equipped with a generous 150 mm diameter viewing screen and capable of high-resolution projection, this microscope is perfect for group demonstrations, allowing everyone to observe specimens clearly and simultaneously. The vertical projection head ensures accurate and uncompromised image display for educational or training sessions.

Versatile and Robust Design

Crafted from a sturdy metal alloy with an anti-corrosive finish, the microscope includes an adjustable mechanical stage and both coarse and fine focusing options. Its flexible power supply range of 110V-240V ensures compatibility with various setups, while the dust cover and included spares promote longevity and easy maintenance.

Comprehensive Imaging Capabilities

Integrated with advanced optics, a high-sensitivity image sensor, and support for both USB and VGA output, this device enables vivid live projections and digital captures. The system excels in live group teaching, documentation, or presentations, supported by adjustable illumination and a fully rotatable, inclined eyepiece tube.

FAQs of Projection Microscope:

Q: How does the projection microscope work for group viewing?

A: The microscope incorporates a projection optics system that displays live images onto a 150 mm diameter screen or directly onto a wall/screen via VGA or USB. Its high-sensitivity sensor and adjustable magnification ensure that the group can observe clear, detailed specimens in real time.

Q: What process should I follow to capture images or videos using this microscope?

A: To capture images or videos, connect the microscope to a compatible device via USB or VGA. Utilize the software provided to take still images at 1280 x 1024 pixels or record videos at 1280 x 720 pixels, ensuring all media is saved in the JPEG format.

Q: When is this projection microscope most beneficial to use?

A: This microscope is exceptionally useful during educational demonstrations, group research activities, or anywhere simultaneous viewing by multiple participants is needed. Its ideal in classrooms, training labs, or group presentations to facilitate interactive discussions and collaborative learning.

Q: Where can this microscope be effectively utilized?

A: The projection microscope is versatile for use in schools, colleges, research laboratories, medical training centers, and demonstration halls. Its robust and anti-corrosive build allows reliable performance in various institutional or laboratory settings.

Q: What is the advantage of having both halogen and LED illumination options?

A: The dual light source option allows users to select the best lighting for different specimens and observation needs. Halogen offers bright, consistent illumination, while LED provides energy efficiency and cooler operation, enhancing specimen clarity during extended viewing sessions.

Q: How do I maintain the microscope for prolonged usage?

A: Regularly clean optical elements with suitable cleaners and always use the included dust cover when not in use. Spare components like lamps, fuses, and eyepieces are easily replaceable, and the anti-corrosive finish of the metal body ensures durability with minimal effort.
